ShockWater Systems
Integration of Multi-Physics into a single package
Advanced Oxidation reaction intensified in the
reaction zone
High flow rate capability – 75k BPD in a single
CONNEX containers
Wide Spectrum of Applications
A two-stage process
RotoCavitator™ Reactor to generate O2H2
and H2O2 radicals
Electro-Chemical Oxide Reactor – an electrochemical
cell that generates free Chlorine from the
O2H2 and O2H2
radicals and their binding to metal (sodium and Iron)
ions.
Generates in excess of 20 ppm Free Chlorine and Chlorine Dioxide
Greater than 0.8 ppm is sufficient for sterilizing
water against microbes
Chlorine production is based upon an electrical current
in the though Electro-Chemical Oxide Reactor.
Free Iron and Hydrogen Sulfide reduced to 0
Iron is precipitated out as a solid - Iron salt (FeClO)
acts as a flocculant for water clarification – Achieve
Turbidity < 10
Hydrogen Sulfide is consumed.
Water Clarification
IDischarge from the trailers is held in 5 frac tanks
for final oxidation, and solids settling.
Anticipate needing to remove solids 1x per year.
Solids are non-Hazardous and are simply buried with
another solid disposal.
The final clarification is through these 40,000 BPD
capacity 6- layer media filters. These filters are
backwashed once per day to the inlet, dirty water frac
tanks.
